神经网络

import tensorflow as tf

print(tf.__version__)

# 下载MNIST数据并进行归一化
mnist = tf.keras.datasets.mnist
(X_train, y_train), (X_test, y_test) = mnist.load_data()
X_train, X_test = X_train / 255.0, X_test / 255.0
print(X_train.shape, X_test.shape, y_train.shape, y_test.shape)

# 第一种构造模型的方式：使用keras序列化API，该方法仅能构造线性神经网络结构
print('1. use keras sequential API to build a neural network')
neural_network_beginner = tf.keras.models.Sequential([
    tf.keras.layers.Input(shape=(28, 28)),
    tf.keras.layers.Flatten(),
    tf.keras.layers.Dense(512, activation='relu'),
    tf.keras.layers.Dense(128, activation='relu'),
    tf.keras.layers.Dense(10, activation='softmax')
])

# 打印模型信息
neural_network_beginner.summary()

# complie函数中的常用配置：优化器、损失函数和评价指标
# categorical_crossentropy和sparse_categorical_crossentropy都是计算多分类crossentropy的，只是对y的格式要求不同。
# 如果是categorical_crossentropy，那y必须为one-hot形式
# 如果是sparse_categorical_crossentropy，那y就是原始的整数形式，比如[1, 0, 2, 0, 2]
neural_network_beginner.compile(optimizer='adam', loss='sparse_categorical_crossentropy', metrics=['accuracy'])

# 训练模型
neural_network_beginner.fit(X_train, y_train, batch_size=64, epochs=5, validation_data=(X_test, y_test))

# 评估结果
print(neural_network_beginner.evaluate(X_test, y_test))

# 第二种构造模型的方式：继承tf.keras.models.Model类，并重写__init__()和call()函数
print('2. use keras model subclassing API to build a neural network for classification')

# 将数据转化为tf.data.Dataset格式
train_ds = tf.data.Dataset.from_tensor_slices((X_train, y_train)).shuffle(10000).batch(64)
test_ds = tf.data.Dataset.from_tensor_slices((X_test, y_test)).batch(64)


class NeuralNetwork(tf.keras.models.Model):
    def __init__(self):
        super(NeuralNetwork, self).__init__()
        self.flatten = tf.keras.layers.Flatten()
        self.hidden_1 = tf.keras.layers.Dense(512, activation='relu')
        self.hidden_2 = tf.keras.layers.Dense(128, activation='relu')
        self.output_layer = tf.keras.layers.Dense(10, activation='softmax')

    def call(self, x):
        x = self.flatten(x)
        x = self.hidden_1(x)
        x = self.hidden_2(x)
        out = self.output_layer(x)
        return out


neural_network_advanced = NeuralNetwork()

# 定义损失函数和优化器
loss_function = tf.keras.losses.SparseCategoricalCrossentropy()
optimizer = tf.keras.optimizers.Adam()

# 评价指标
train_loss = tf.keras.metrics.Mean(name='train_loss')
train_accuracy = tf.keras.metrics.SparseCategoricalAccuracy(name='train_accuracy')

test_loss = tf.keras.metrics.Mean(name='test_loss')
test_accuracy = tf.keras.metrics.SparseCategoricalAccuracy(name='test_accuracy')


# 定义训练步
@tf.function
def train_step(images, labels):
    with tf.GradientTape() as tape:
        predictions = neural_network_advanced(images)
        loss = loss_function(labels, predictions)
    gradients = tape.gradient(loss, neural_network_advanced.trainable_variables)
    optimizer.apply_gradients(zip(gradients, neural_network_advanced.trainable_variables))

    train_loss(loss)
    train_accuracy(labels, predictions)


# 定义测试步
@tf.function
def test_step(images, labels):
    predictions = neural_network_advanced(images)
    loss = loss_function(labels, predictions)

    test_loss(loss)
    test_accuracy(labels, predictions)


EPOCHS = 5  # 训练轮次

for epoch in range(EPOCHS):
    # 每个epoch开始时将指标重置
    train_loss.reset_states()
    train_accuracy.reset_states()
    test_loss.reset_states()
    test_accuracy.reset_states()

    for images, labels in train_ds:
        train_step(images, labels)

    for test_images, test_labels in test_ds:
        test_step(test_images, test_labels)

    template = 'Epoch {}, Loss: {}, Accuracy: {}, Test Loss: {}, Test Accuracy: {}'
    print(template.format(epoch + 1, train_loss.result(), train_accuracy.result() * 100,
                          test_loss.result(), test_accuracy.result() * 100))

import torch
import numpy as np
from torchvision.datasets import mnist  # 导入pytorch内置的mnist数据集
import torchvision.transforms as transforms  # 导入对图像的预处理模块
from torch.utils.data import DataLoader  # 导入dataset的分批读取包
from torch import nn  # 导入神经网络包nn（可用来定义和运行神经网络）
# functional中包含了神经网络中使用的一些常用函数，这些函数的特点是:不具有可学习的参数(如ReLU，pool，DropOut等)
import torch.nn.functional as F
import torch.optim as optim  # optim中实现了大多数的优化方法来更新网络权重和参数，如SGD、Adam

# 定义代码中用到的各个超参数
train_batch_size = 64  # 指定DataLoader在训练集中每批加载的样本数量
test_batch_size = 128  # 指定DataLoader在测试集中每批加载的样本数量
num_epoches = 20  # 模型训练轮数
lr = 0.01  # 设置SGD中的初始学习率
momentum = 0.5  # 设置SGD中的冲量

# 对数据进行预处理
# Compose方法即是将两个操作合并一起
# 使用minst数据集的均值和标准差将数据标准化处理
transform = transforms.Compose([transforms.ToTensor(), transforms.Normalize([0.1307], [0.3081])])

# 下载和分批加载数据集

# 将训练和测试数据集下载到同目录下的mnist_data文件夹下
train_dataset = mnist.MNIST('.\mnist_data', train=True, transform=transform, download=True)
test_dataset = mnist.MNIST('.\mnist_data', train=False, transform=transform, download=True)

# dataloader是一个可迭代对象，可以使用迭代器一样使用。其中shuffle参数为是否打乱原有数据顺序
train_loader = DataLoader(train_dataset, batch_size=train_batch_size, shuffle=True)
test_loader = DataLoader(test_dataset, batch_size=test_batch_size, shuffle=False)


# 定义一个神经网络模型
class Net(nn.Module):
    def __init__(self, in_dim, n_hidden_1, n_hidden_2, out_dim):
        super(Net, self).__init__()
        self.layer1 = nn.Sequential(nn.Linear(in_dim, n_hidden_1), nn.ReLU(True))
        self.layer2 = nn.Sequential(nn.Linear(n_hidden_1, n_hidden_2), nn.ReLU(True))
        self.layer3 = nn.Linear(n_hidden_2, out_dim)  # 最后一层接Softmax所以不需要ReLU激活

        x = self.layer1(x)

    def forward(self, x):
        x = self.layer2(x)
        x = self.layer3(x)
        return x


# Sequential() 即相当于把多个模块按顺序封装成一个模块

# 实例化网络模型
device = torch.device('cuda:0' if torch.cuda.is_available() else 'cpu')
# 网络模型参数分别为：输入层大小、隐藏层1大小、隐藏层2大小、输出层大小（10分类）
model = Net(28 * 28, 300, 100, 10)
# 将模型移动到GPU加速计算
model.to(device)

# 定义模型训练中用到的损失函数和优化器
criterion = nn.CrossEntropyLoss()  # 交叉熵损失函数
optimizer = optim.SGD(model.parameters(), lr=lr, momentum=momentum)
# parameters()将model中可优化的参数传入到SGD中

# 对模型进行训练
losses = []  # 记录训练集损失
acces = []  # 记录训练集准确率
eval_losses = []  # 记录测试集损失
eval_acces = []  # 记录测试集准确率

for epoch in range(num_epoches):
    train_loss = 0
    train_acc = 0
    model.train()  # 指明接下来model进行的是训练过程
    # 动态修改参数学习率
    if epoch % 5 == 0:
        optimizer.param_groups[0]['lr'] *= 0.9
    for img, label in train_loader:
        img = img.to(device)  # 将img移动到GPU计算
        label = label.to(device)
        img = img.view(img.size(0), -1)  # 把输入图像的维度由四维转化为2维，因为在torch中只能处理二维数据
        # img.size(0)为取size的第0个参数即此批样本的个数，-1为自适应参数
        # 前向传播
        out = model(img)
        loss = criterion(out, label)
        # 反向传播
        optimizer.zero_grad()  # 先清空上一轮的梯度
        loss.backward()  # 根据前向传播得到损失，再由损失反向传播求得各个梯度
        optimizer.step()  # 根据反向传播得到的梯度优化模型中的参数

        train_loss += loss.item()  # 所有批次损失的和
        # 计算分类的准确率
        _, pred = out.max(1)  # 返回输出二维矩阵中每一行的最大值及其下标，1含义为以第1个维度（列）为参考
        num_correct = (pred == label).sum().item()
        acc = num_correct / img.shape[0]  # 每一批样本的准确率
        train_acc += acc

    losses.append(train_loss / len(train_loader))  # 所有样本平均损失
    acces.append(train_acc / len(train_loader))  # 所有样本的准确率

    # 运用训练好的模型在测试集上检验效果
    eval_loss = 0
    eval_acc = 0
    # 将模型改为预测模式
    model.eval()  # 指明接下来要进行模型测试（不需要反向传播）
    # with torch.no_grad():
    for img, label in test_loader:
        img = img.to(device)
        label = label.to(device)
        img = img.view(img.size(0), -1)
        out = model(img)
        loss = criterion(out, label)
        # 记录误差
        eval_loss += loss.item()
        # 记录准确率
        _, pred = out.max(1)
        num_correct = (pred == label).sum().item()
        acc = num_correct / img.shape[0]
        eval_acc += acc

    eval_losses.append(eval_loss / len(test_loader))
    eval_acces.append(eval_acc / len(test_loader))

    print('epoch: {}, Train Loss: {:.4f}, Train Acc: {:.4f}, Test Loss: {:.4f}, Test Acc: {:.4f}'
          .format(epoch, train_loss / len(train_loader), train_acc / len(train_loader),
                  eval_loss / len(test_loader), eval_acc / len(test_loader)))
